Digital Logic and Designs (CSE1003) Crossword

The sequential Circuits are designed using the combinational circuits along with a memory devices known as ________.
The ______ do not have clock input but flip flop has a clock input
A sequential circuit which is used to display the number of time any event is repeated or happening.
A group of flip flop which holds the binary information
A ripple counter is an ______________ counter.
A sequence of equally spaced timing pulses may be easily generated by a(n) __________.
Asynchronous counters are often called ________ counters.
Asynchronous sequential circuits do not use ______ signals as synchronous circuits do.
A universal gate
Helpful to simplify Boolean expressions with limited inputs
Output is high, when any one of the input is high
the circuit can go into the wrong state depending on slight differences in the propagation delays of the gates which is known as ________.
A sequential circuit where only the first flip-flop is clocked by an external clock.
A fixed architecture logic device with programmable AND gates followed by programmable OR gates.
It has programmable AND array and fixed OR array.
