CAD TERMS Crossword

Make a hole in something, especially with a revolving tool
A slope from the horizontal or vertical in carpentry or stonework
A break in an object
A slope from the horizontal or vertical in carpentry or stonework
500 sheets of paper
Establishes a connection between a graphical representation or an item and some text
The center of a building plan
The amount of something that is permitted, especially within a set of regulations or for a specified purpose
American National Standards Institute
Used to represent surfaces that are not directly visible or modeling of form
Used to represent surfaces that are not directly visible or modeling of form
An outside corner which is curved on a part
Lines that are made visible as dots or dashes to reveal the edges of objects currently hidden from view
A drawing pr sketch restricted to a line without shaded or modeling of form
Engineering Change order - documentation packet outlines
A light line that extends from the edge or end of a main object
A point or level beyond which something does or may not extend or pass; a restriction on the size or amount of something permissible or possible
make the surface of something smooth and shiny by rubbing it
Creates the first tolerance value in the feature control frame
Inside a corner of a part
Heating and cooling of a metal or alloy to obtain desired properties or conditions
Boundary line of a section, or parallel lines placed on the cut surfaces of section views
The act or an instance of inspecting or testing something
Forming an essential foundation or starting point
One or more printed sheets showing a manufacturers parts or assemblies of an end item by illustration
A hand tool, power tool, or machine with a rotating cutting tip or reciprocating hammer of chisel
Reduce something to small particles or powder by crushing it
A narrow part of something, resembling in shape or position
Standard length or measurement of a piece of paper for drafting industry
Object used to create a part
