Crossword Puzzle on Diodes and BJT

This printable crossword puzzle on the topic of Physics has 18 clues. Answers range from 2 to 10 letters long. This crossword is also available to download as a Microsoft Word document or a PDF.

This circuit is also called as limiter
Input waveform shifted in positive or negative direction
Converts AC to pulsating DC
AC content in DC output
Used for voltage regulation
Works on electroluminescence
Output is twice the peak value of input
Converts light energy to electric energy
Current controlled device
Voltage controlled device
Heavily doped region of BJT
BJT region having largest area
BJT acts as ON switch in __________region
BJT acts as OPEN switch in _____________ region
_____________terminal of MOSFET is similar to emitter in BJT
_____________terminal of MOSFET is similar to collector in BJT
Voltage gain is less than 1 in ___ configuration
Both the voltage gain and current gain are greater than 1 in___ configuration
