OPAMP & ITS APPLICATIONS Crossword

This printable crossword puzzle on the topic of Physics has 15 clues. Answers range from 3 to 21 letters long. This crossword is also available to download as a Microsoft Word document or a PDF.

A --------- is a part of OPAMP
In the ................... an identical signal appears in i/ps
The common-mode gain is very
The differential gain is very
If Vin is 0, Vo is
The use of negative feedback ................. the voltage gain
Negative feedback ................. the Zin and B.W
A voltage follower has .............. of 1
Op-amp can ........... both a.c. and d.c.
The input offset current equals .............. between base currents
The tail current in a differential amplifier equals sum of two emitter currents
A ............ signal is applied to both inputs
The............. stage of an Op-amp is usually a differential amplifier
.............. cannot flow to ground through a virtual ground
emitter-follower has ............... Zin and low Zo
